External Laptop notebook Battery charger fo FUJITSU S6310 S6311 S7110 S7111 FPCBP145 FPCBP200 FPCBP200AP FPCBP215AP T1010 T4310 |

External Laptop notebook Battery charger fo FUJITSU S6310 S6311 S7110 S7111 FPCBP145 FPCBP200 FPCBP200AP FPCBP215AP T1010 T4310 |

DESCRIPTION:

Basic Parameters
Model No.: LZY-NC6
Dimensions: 128*51.5*33 mm
Color: black
Weight: 200g
Input Voltage: AC 100~240V
Maximum output power: 40W
Standby power consumption: <1W
Output voltage: DC 7.2~14.8V
Maximum output current: 2.5A
Warranty: one year
Length of charging time: 8 hours MAX(Different charging time for batteries of different capacity)
Safety Standard: CE standard (UL, CB, GS, T-Mark etc. can be made as customers’ requirements)

Charging Instruction
1. Normal Working Condition:
Four charging lights and the power light go on after switching on.
The charger acquires the battery information from the battery protective plate, and then starts charging.

FOR MOST FUJITSU BATTERIES, THERE ARE ONLY 2 LEDs STATUS FOR CHARGING.

Charging LED STATUS Capacity Percentage
All the four LEDs blink circularly    < 100%
All the four LEDs are on                =100%
2. Activate Charging Condition:
The four charging lights blink synchronously after switching on. It might be the charger is not connected well with the battery. Users should check and confirm the device is connected correctly.
One minute later, if the charger enters normal working condition, it means the battery has been activated.
One minute later, if the four charging lights still blink synchronously, it means the battery has been damaged and can not be repaired.

Cautions
1. To avoid explosion and danger, damaged batteries and leaking batteries are not allowed.
2. This product is good for indoors. Do not expose and use it in outdoors.
3. Do not drop or put something heavy on it. Children are not allowed to use the product without adults.
4. The operation temperature must be 0~40 C

5. Do not keep the product under the direct rays, beside the hot devices or in other hot environment.
6. Do not disassemble or assemble the product.

Functions:

This product is a portable charger for high capacity batteries of laptop

1. Charge your laptop battery directly.

2. Suitable for over 95% of laptops in market with the separate connecting wire.

3. With four LED lights to indicate the charge status.

4. Charge your USB peripherals with the USB port.

5. Charge voltage and current can be regulated automatically.

6.  Simplify charging process, save your time and preserve your laptop, especially when you own two batteries or your laptop cannot charge the battery normally.

Basic Parameters

Safety Standard: CE standard (UL, CB, GS, T-Mark etc. can be made as customers’requirements)

Input Voltage: DC 20V

Maximum Input Current: 2A MAX

USB Output: 5V±4%;≤500MA

Standby power consumption: <1W

With the repair zero-voltage-battery function

Can realize lithium battery pack with the different combination

Easy to carry: put it in your journey bag, computer bag or car.

Length of charging time: 8 hours MAX(Different charging time for batteries of different capacity)

Charging Instruction

1. Normal Working Condition:

Four LED lights go on after switching on. The charger gains the battery information from the battery protective plate, and then starts charging.

       This model is specially designed for FUJITSU laptop batteries, and it could be ok for most of FUJITSU same pins laptop batteries,but not for 100% models. Please send us message to confirm before ordering.Thanks!
