4 Road Motor Drive Module Trolley Motor Drive L298N H Bridge Positive Inversion Control

Description:

Module parameters:

1 the size of the module: 5.2*5.1cm

2 the maximum power consumption: 50W (temperature T = 75 DEG C, monolithic L298N 25W)

3.The peak current of Io:4A drive

4.The logical part of terminal power supply range: 5V ~ + Vss + 7V (5V + power taking plate)

5 logic parts working current range: 0 ~ 36mA

6.The control signal input voltage range:

Low level: 0.3V ≤ Vin ≤ 1.5V

High level: 2.3V≤ Vin ≤ Vss

7.The enable signal input voltage range:

Low level: 0.3≤ Vin ≤ 1.5V (control signal is invalid)

High level: 2.3V ≤ Vin ≤ Vss (effective control signal)

8 storage temperature: - 25 ~ 130 degrees Celsius

9.Module quality: 46.3 grams

Wiring instructions:

IN1-IN8: motor logic control end, where IN1/IN2 control motor 1; IN3/IN4 control motor 2; IN5/IN6 control motor 3; IN7/IN8 control motor 4
EN1-EN4:EN1 is the power of the motor 1 terminal EN2 is the motor of the enable terminal EN3 is the motor of the power of the 3 EN4 is the power of the motor 4 of the end
ON/OFF: internal power supply, when the control voltage of the motor in the 7-35V , the jumper cap jump to ON end, this can provide 5V power to an external controller; when control motor voltage is less than 7V, jump to the jumper cap at one end of the OFF, then we need to provide a stable external power supply to the 5V chip power supply module.
VIN/GND: motor power interface
When the VCC/GND: jumper is ON, this VCC can be used as an output. When the jumper is OFF, the VCC needs to be connected to the 5V power supply from the outside
MOT1-MOT4:4 Motor Interface

Package Included:

1 * 4 Road Motor Drive Module

.
